超微X11SRL-F 服務器主板C422/LGA 2066 返回

產品詳情

超微X11SRL-F 服務器主板 ATX/C422/LGA 2066



Product SKUs

MBD-X11SRL-F

  • X11SRL-F


Physical Stats

Form Factor

  • ATX

Dimensions

  • 12" x 9.6" (30.48cm x 24.38cm)


Processor/Cache

CPU

  • Intel? Xeon? W-2100 Processors, Intel? Xeon? W-2200 Processors

  • Single Socket LGA-2066 (Socket R4) supported, CPU TDP supports Up to 165W TDP

Cores / Cache

  • 18 cores, 36 threads

Note

  • W-2200 CPU is supported on the motherboards with BIOS 2.0 or newer upon receiving from Supermicro

Note

  • To support 165W W-2200 CPUs, BIOS 2.0 & VRM update by Supermicro are required


System Memory

Memory Capacity

  • Up to 512GB ECC RDIMM, DDR4-2933MHz; Up to 1TB Registered ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots

Memory Type

  • 2666/2400/2133MHz ECC DDR4 RDIMM, LRDIMM

DIMM Sizes

  • 4GB, 8GB, 16GB, 32GB, 64GB, 128GB

Memory Voltage

  • 1.2V

Error Detection

  • Corrects single-bit errors


On-Board Devices

Chipset

  • Intel? C422

SATA

  • Intel? C422 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10

IPMI

  • ASPEED AST2500

Network Controllers

  • Dual LAN with Intel? i210 Gigabit Ethernet Controller

Graphics

  • ASPEED AST2500 BMC


Input / Output

SATA

  • 8 SATA3 (6Gbps) ports

LAN

  • 2 RJ45 Gigabit Ethernet LAN ports

USB

  • 6 USB 2.0 ports (2 rear + 4 via headers)

  • 5 USB 3.2 Gen1 ports (2 rear + 2 via headers + 1 Type A)

Video Output

  • 1 VGA port

Serial Port / Header

  • 2 COM Ports (1 rear, 1 header)

TPM

  • TPM Header
